Android實現偵聽電池狀態顯示、電量及充電動態顯示的方法

本文實例講述了Android實現偵聽電池狀態顯示、電量及充電動態顯示的方法，是Android應用程序開發中非常常用的重要功能。分享給大家供大家參考之用。具體方法如下：

使用android系統的電池偵聽和系統的電池圖片如下；

引入源代碼中的兩個xml文件（這裡我在android2.2的jar包中找不到，所以才引入，源代碼路徑：C:\android-sdk-windows\platforms\android-8\data\res\drawable），之後會發現stat_sys_battery.xml報錯，如下圖所示：


1.這些圖引入到我的drawable目錄下，然後將stat_sys_battery.xml中的圖片引入路徑更改，如下：

<level-list xmlns:android="http://schemas.android.com/apk/res/android">
 <item android:maxLevel="4" android:drawable="@drawable/stat_sys_battery_0" />
 <item android:maxLevel="14" android:drawable="@drawable/stat_sys_battery_10" />
 <item android:maxLevel="29" android:drawable="@drawable/stat_sys_battery_20" />
 <item android:maxLevel="49" android:drawable="@drawable/stat_sys_battery_40" />
 <item android:maxLevel="69" android:drawable="@drawable/stat_sys_battery_60" />
 <item android:maxLevel="89" android:drawable="@drawable/stat_sys_battery_80" />
 <item android:maxLevel="100" android:drawable="@drawable/stat_sys_battery_100" />
</level-list>

2.接下來是在activity中的操作：

創建一個IntentFilter

private IntentFilter mIntentFilter;

在oncreate的方法中：加入：

//電池相關
mIntentFilter = new IntentFilter();
mIntentFilter.addAction(Intent.ACTION_BATTERY_CHANGED);

3.接收廣播

//聲明消息處理過程
private BroadcastReceiver mIntentReceiver = new BroadcastReceiver() {
  @Override
  public void onReceive(Context context, Intent intent) {
   String action = intent.getAction();
   int status = intent.getIntExtra("status", 0);
   int health = intent.getIntExtra("health", 0);
   boolean present = intent.getBooleanExtra("present", false);
   int level = intent.getIntExtra("level", 0);
   int scale = intent.getIntExtra("scale", 0);
   int icon_small = intent.getIntExtra("icon-small", 0);
   int plugged = intent.getIntExtra("plugged", 0);
   int voltage = intent.getIntExtra("voltage", 0);
   int temperature = intent.getIntExtra("temperature", 0);
   String technology = intent.getStringExtra("technology");
   String statusString = "";
   switch (status) {
   case BatteryManager.BATTERY_STATUS_UNKNOWN:
    statusString = "unknown";
    break;
   case BatteryManager.BATTERY_STATUS_CHARGING:
    statusString = "charging";
    battery_image.setImageResource(R.drawable.stat_sys_battery_charge);
    battery_image.getDrawable().setLevel(level);
    break;
   case BatteryManager.BATTERY_STATUS_DISCHARGING:
    statusString = "discharging";
    battery_image.setImageResource(R.drawable.stat_sys_battery);
    battery_image.getDrawable().setLevel(level);
    break;
   case BatteryManager.BATTERY_STATUS_NOT_CHARGING:
    statusString = "not charging";
    break;
   case BatteryManager.BATTERY_STATUS_FULL:
    statusString = "full";
    break;
   }
   String healthString = "";
   switch (health) {
   case BatteryManager.BATTERY_HEALTH_UNKNOWN:
    healthString = "unknown";
    break;
   case BatteryManager.BATTERY_HEALTH_GOOD:
    healthString = "good";
    break;
   case BatteryManager.BATTERY_HEALTH_OVERHEAT:
    healthString = "overheat";
    break;
   case BatteryManager.BATTERY_HEALTH_DEAD:
    healthString = "dead";
    break;
   case BatteryManager.BATTERY_HEALTH_OVER_VOLTAGE:
    healthString = "voltage";
    break;
   case BatteryManager.BATTERY_HEALTH_UNSPECIFIED_FAILURE:
    healthString = "unspecified failure";
    break;
   }
   String acString = "";
   switch (plugged) {
   case BatteryManager.BATTERY_PLUGGED_AC:
    acString = "plugged ac";
    break;
   case BatteryManager.BATTERY_PLUGGED_USB:
    acString = "plugged usb";
    break;
   }
   Log.i("cat", statusString);
   Log.i("cat", healthString);
   Log.i("cat", String.valueOf(present));
   Log.i("cat", String.valueOf(level));
   Log.i("cat", String.valueOf(scale));
   Log.i("cat", String.valueOf(icon_small));
   Log.i("cat", acString);
   Log.i("cat", String.valueOf(voltage));
   Log.i("cat", String.valueOf(temperature));
   Log.i("cat", technology);
   //要看看是不是我們要處理的消息
   if (action.equals(Intent.ACTION_BATTERY_CHANGED)) {
    //電池電量，數字
    Log.d("Battery", "" + intent.getIntExtra("level", 0));
    //電池最大容量
    Log.d("Battery", "" + intent.getIntExtra("scale", 0));
    //電池伏數
    Log.d("Battery", "" + intent.getIntExtra("voltage", 0));
    //電池溫度
    Log.d("Battery", "" + intent.getIntExtra("temperature", 0));
    //電池狀態，返回是一個數字
    // BatteryManager.BATTERY_STATUS_CHARGING 表示是充電狀態
    // BatteryManager.BATTERY_STATUS_DISCHARGING 放電中
    // BatteryManager.BATTERY_STATUS_NOT_CHARGING 未充電
    // BatteryManager.BATTERY_STATUS_FULL 電池滿
    Log.d("Battery", "ss" + intent.getIntExtra("status", BatteryManager.BATTERY_STATUS_CHARGING));
    //充電類型 BatteryManager.BATTERY_PLUGGED_AC 表示是充電器，不是這個值，表示是 USB
    Log.d("Battery", "" + intent.getIntExtra("plugged", 0));
    //電池健康情況，返回也是一個數字
    //BatteryManager.BATTERY_HEALTH_GOOD 良好
    //BatteryManager.BATTERY_HEALTH_OVERHEAT 過熱
    //BatteryManager.BATTERY_HEALTH_DEAD 沒電
    //BatteryManager.BATTERY_HEALTH_OVER_VOLTAGE 過電壓
    //BatteryManager.BATTERY_HEALTH_UNSPECIFIED_FAILURE 未知錯誤
    Log.d("Battery", "" + intent.getIntExtra("health", BatteryManager.BATTERY_HEALTH_UNKNOWN));
   }
  }
 };

這裡真正處理圖片變換的是以下幾句話：

switch (status) {
case BatteryManager.BATTERY_STATUS_UNKNOWN:
 statusString = "unknown";
 break;
case BatteryManager.BATTERY_STATUS_CHARGING:
 statusString = "charging";
 battery_image.setImageResource(R.drawable.stat_sys_battery_charge);
 battery_image.getDrawable().setLevel(level);
 break;
case BatteryManager.BATTERY_STATUS_DISCHARGING:
 statusString = "discharging";
 battery_image.setImageResource(R.drawable.stat_sys_battery);
 battery_image.getDrawable().setLevel(level);
 break;
case BatteryManager.BATTERY_STATUS_NOT_CHARGING:
 statusString = "not charging";
 break;
case BatteryManager.BATTERY_STATUS_FULL:
 statusString = "full";
 break;
}

4.在onResume方法中注冊消息處理器

registerReceiver(mIntentReceiver, mIntentFilter);

5.在onPause方法中注銷

unregisterReceiver(mIntentReceiver);

希望本文所述對大家的Android程序設計有所幫助。
