Android仿微信語音聊天界面設計

有段時間沒有看視頻了，昨天晚上抽了點空時間，又看了下鴻洋大神的視頻教程，又抽時間寫了個學習記錄。代碼和老師講的基本一樣，網上也有很多相同的博客。我只是在AndroidStudio環境下寫的。

—-主界面代碼——

 public class MainActivity extends Activity {
 private ListView mListView;
 private ArrayAdapter<Recorder> mAdapter;
 private List<Recorder> mDatas = new ArrayList<Recorder>();
 private AudioRecorderButton mAudioRecorderButton;
 private View animView;

 @Override
 protected void onCreate(Bundle savedInstanceState) {
  super.onCreate(savedInstanceState);
  setContentView(R.layout.activity_main);
  mListView = (ListView) findViewById(R.id.id_listview);
  mAudioRecorderButton = (AudioRecorderButton) findViewById(R.id.id_recorder_button);
  mAudioRecorderButton.setFinishRecorderCallBack(new AudioRecorderButton.AudioFinishRecorderCallBack() {

   public void onFinish(float seconds, String filePath) {
    Recorder recorder = new Recorder(seconds, filePath);
    mDatas.add(recorder);
    //更新數據
    mAdapter.notifyDataSetChanged();
    //設置位置
    mListView.setSelection(mDatas.size() - 1);
   }
  });

  mAdapter = new RecoderAdapter(this, mDatas);
  mListView.setAdapter(mAdapter);

  //listView的item點擊事件
  mListView.setOnItemClickListener(new OnItemClickListener() {

   public void onItemClick(AdapterView<?> arg0, View view, int position, long id) {
    // 聲音播放動畫
    if (animView != null) {
     animView.setBackgroundResource(R.drawable.adj);
     animView = null;
    }
    animView = view.findViewById(R.id.id_recoder_anim);
    animView.setBackgroundResource(R.drawable.play_anim);
    AnimationDrawable animation = (AnimationDrawable) animView.getBackground();
    animation.start();
    // 播放錄音
    MediaPlayerManager.playSound(mDatas.get(position).filePath, new MediaPlayer.OnCompletionListener() {

     public void onCompletion(MediaPlayer mp) {
      //播放完成後修改圖片
      animView.setBackgroundResource(R.drawable.adj);
     }
    });
   }
  });
 }

 @Override
 protected void onPause() {
  super.onPause();
  MediaPlayerManager.pause();
 }

 @Override
 protected void onResume() {
  super.onResume();
  MediaPlayerManager.resume();
 }

 @Override
 protected void onDestroy() {
  super.onDestroy();
  MediaPlayerManager.release();
 }

—自定義Button——-

/**
 * @param
 * @author ldm
 * @description 自定義Button
 * @time 2016/6/25 9:26
 */
public class AudioRecorderButton extends Button {
 // 按鈕正常狀態（默認狀態）
 private static final int STATE_NORMAL = 1;
 //正在錄音狀態
 private static final int STATE_RECORDING = 2;
 //錄音取消狀態
 private static final int STATE_CANCEL = 3;
 //記錄當前狀態
 private int mCurrentState = STATE_NORMAL;
 //是否開始錄音標志
 private boolean isRecording = false;
 //判斷在Button上滑動距離，以判斷 是否取消
 private static final int DISTANCE_Y_CANCEL = 50;
 //對話框管理工具類
 private DialogManager mDialogManager;
 //錄音管理工具類
 private AudioManager mAudioManager;
 //記錄錄音時間
 private float mTime;
 // 是否觸發longClick
 private boolean mReady;
 //錄音准備
 private static final int MSG_AUDIO_PREPARED = 0x110;
 //音量發生改變
 private static final int MSG_VOICE_CHANGED = 0x111;
 //取消提示對話框
 private static final int MSG_DIALOG_DIMISS = 0x112;

 /**
  * @description 獲取音量大小的線程
  * @author ldm
  * @time 2016/6/25 9:30
  * @param
  */
 private Runnable mGetVoiceLevelRunnable = new Runnable() {

  public void run() {
   while (isRecording) {//判斷正在錄音
    try {
     Thread.sleep(100);
     mTime += 0.1f;//錄音時間計算
     mHandler.sendEmptyMessage(MSG_VOICE_CHANGED);//每0.1秒發送消息
    } catch (InterruptedException e) {
     e.printStackTrace();
    }
   }
  }
 };

 private Handler mHandler = new Handler() {

  @Override
  public void handleMessage(Message msg) {
   switch (msg.what) {
    case MSG_AUDIO_PREPARED:
     //顯示對話框
     mDialogManager.showRecordingDialog();
     isRecording = true;
     // 開啟一個線程計算錄音時間
     new Thread(mGetVoiceLevelRunnable).start();
     break;
    case MSG_VOICE_CHANGED:
     //更新聲音
     mDialogManager.updateVoiceLevel(mAudioManager.getVoiceLevel(7));
     break;
    case MSG_DIALOG_DIMISS:
     //取消對話框
     mDialogManager.dimissDialog();
     break;
   }
   super.handleMessage(msg);
  }
 };


 public AudioRecorderButton(Context context, AttributeSet attrs) {
  super(context, attrs);
  mDialogManager = new DialogManager(context);
  //錄音文件存放地址
  String dir = Environment.getExternalStorageDirectory() + "/ldm_voice";
  mAudioManager = AudioManager.getInstance(dir);
  mAudioManager.setOnAudioStateListener(new AudioManager.AudioStateListener() {
   public void wellPrepared() {
    mHandler.sendEmptyMessage(MSG_AUDIO_PREPARED);
   }
  });

  // 由於這個類是button所以在構造方法中添加監聽事件
  setOnLongClickListener(new OnLongClickListener() {

   public boolean onLongClick(View v) {
    mReady = true;
    mAudioManager.prepareAudio();
    return false;
   }
  });
 }

 public AudioRecorderButton(Context context) {
  this(context, null);
 }

 /**
  * @description 錄音完成後的回調
  * @author ldm
  * @time 2016/6/25 11:18
  * @param
 */
 public interface AudioFinishRecorderCallBack {
  void onFinish(float seconds, String filePath);
 }

 private AudioFinishRecorderCallBack finishRecorderCallBack;

 public void setFinishRecorderCallBack(AudioFinishRecorderCallBack listener) {
  finishRecorderCallBack = listener;
 }

 /**
  * @param
  * @description 處理Button的OnTouchEvent事件
  * @author ldm
  * @time 2016/6/25 9:35
  */
 @Override
 public boolean onTouchEvent(MotionEvent event) {
  //獲取TouchEvent狀態
  int action = event.getAction();
  // 獲得x軸坐標
  int x = (int) event.getX();
  // 獲得y軸坐標
  int y = (int) event.getY();

  switch (action) {
   case MotionEvent.ACTION_DOWN://手指按下
    changeState(STATE_RECORDING);
    break;
   case MotionEvent.ACTION_MOVE://手指移動
    if (isRecording) {
     //根據x,y的坐標判斷是否需要取消
     if (wantToCancle(x, y)) {
      changeState(STATE_CANCEL);
     } else {
      changeState(STATE_RECORDING);
     }
    }

    break;
   case MotionEvent.ACTION_UP://手指放開
    if (!mReady) {
     reset();
     return super.onTouchEvent(event);
    }
    if (!isRecording || mTime < 0.6f) {//如果時間少於0.6s，則提示錄音過短
     mDialogManager.tooShort();
     mAudioManager.cancel();
     // 延遲顯示對話框
     mHandler.sendEmptyMessageDelayed(MSG_DIALOG_DIMISS, 1000);
    } else if (mCurrentState == STATE_RECORDING) {
     //如果狀態為正在錄音，則結束錄制
     mDialogManager.dimissDialog();
     mAudioManager.release();

     if (finishRecorderCallBack != null) {
      finishRecorderCallBack.onFinish(mTime, mAudioManager.getCurrentFilePath());
     }

    } else if (mCurrentState == STATE_CANCEL) { // 想要取消
     mDialogManager.dimissDialog();
     mAudioManager.cancel();
    }
    reset();
    break;

  }
  return super.onTouchEvent(event);
 }

 /**
  * 恢復狀態及標志位
  */
 private void reset() {
  isRecording = false;
  mTime = 0;
  mReady = false;
  changeState(STATE_NORMAL);
 }

 private boolean wantToCancle(int x, int y) {
  // 超過按鈕的寬度
  if (x < 0 || x > getWidth()) {
   return true;
  }
  // 超過按鈕的高度
  if (y < -DISTANCE_Y_CANCEL || y > getHeight() + DISTANCE_Y_CANCEL) {
   return true;
  }

  return false;
 }


 /**
  * @param
  * @description 根據狀態改變Button顯示
  * @author ldm
  * @time 2016/6/25 9:36
  */
 private void changeState(int state) {
  if (mCurrentState != state) {
   mCurrentState = state;
   switch (state) {
    case STATE_NORMAL:
     setBackgroundResource(R.drawable.btn_recorder_normal);
     setText(R.string.str_recorder_normal);
     break;

    case STATE_RECORDING:
     setBackgroundResource(R.drawable.btn_recorder_recording);
     setText(R.string.str_recorder_recording);
     if (isRecording) {
      mDialogManager.recording();
     }
     break;

    case STATE_CANCEL:
     setBackgroundResource(R.drawable.btn_recorder_recording);
     mDialogManager.wantToCancel();
     setText(R.string.str_recorder_want_cancel);
     break;
   }
  }
 }
}

—-對話框管理工具類——

/**
  * @description 對話框管理工具類
  * @author ldm
  * @time 2016/6/25 11:53
  * @param
 */
public class DialogManager {
 //彈出對話框
 private Dialog mDialog;
 //錄音圖標
 private ImageView mIcon;
 //音量顯示 圖標
 private ImageView mVoice;
 //對話框上提示文字
 private TextView mLable;
 //上下文對象
 private Context mContext;


 public DialogManager(Context context) {
  this.mContext = context;
 }

 /**
  * @param
  * @description 顯示對話框
  * @author ldm
  * @time 2016/6/25 9:56
  */
 public void showRecordingDialog() {
  //根據指定sytle實例化Dialog
  mDialog = new Dialog(mContext, R.style.AudioDialog);
  LayoutInflater inflater = LayoutInflater.from(mContext);
  View view = inflater.inflate(R.layout.dialog_recorder, null);
  mDialog.setContentView(view);
  mIcon = (ImageView) view.findViewById(R.id.id_recorder_dialog_icon);
  mVoice = (ImageView) view.findViewById(R.id.id_recorder_dialog_voice);
  mLable = (TextView) view.findViewById(R.id.id_recorder_dialog_label);
  mDialog.show();
 }

 /**
  * @param
  * @description 正在錄音狀態的對話框
  * @author ldm
  * @time 2016/6/25 10:08
  */
 public void recording() {
  if (mDialog != null && mDialog.isShowing()) {
   mIcon.setVisibility(View.VISIBLE);
   mVoice.setVisibility(View.VISIBLE);
   mLable.setVisibility(View.VISIBLE);
   mIcon.setImageResource(R.drawable.recorder);
   mLable.setText("手指上滑，取消發送");
  }
 }

 /**
  * @param
  * @description 取消錄音狀態對話框
  * @author ldm
  * @time 2016/6/25 10:08
  */
 public void wantToCancel() {
  if (mDialog != null && mDialog.isShowing()) {
   mIcon.setVisibility(View.VISIBLE);
   mVoice.setVisibility(View.GONE);
   mLable.setVisibility(View.VISIBLE);
   mIcon.setImageResource(R.drawable.cancel);
   mLable.setText("松開手指，取消發送");
  }
 }

 /**
  * @param
  * @description時間過短提示的對話框
  * @author ldm
  * @time 2016/6/25 10:09
  */
 public void tooShort() {
  if (mDialog != null && mDialog.isShowing()) { //顯示狀態
   mIcon.setVisibility(View.VISIBLE);
   mVoice.setVisibility(View.GONE);
   mLable.setVisibility(View.VISIBLE);
   mIcon.setImageResource(R.drawable.voice_to_short);
   mLable.setText("錄音時間過短");
  }
 }

 /**
  * @param
  * @description
  * @author ldm
  * @time 2016/6/25 取消（關閉）對話框
  */
 public void dimissDialog() {
  if (mDialog != null && mDialog.isShowing()) { //顯示狀態
   mDialog.dismiss();
   mDialog = null;
  }
 }

 // 顯示更新音量級別的對話框
 public void updateVoiceLevel(int level) {
  if (mDialog != null && mDialog.isShowing()) { //顯示狀態
   mIcon.setVisibility(View.VISIBLE);
   mVoice.setVisibility(View.VISIBLE);
   mLable.setVisibility(View.VISIBLE);
   //設置圖片的id，我們放在drawable中的聲音圖片是以v+數字格式的
   int resId = mContext.getResources().getIdentifier("v" + level, "drawable", mContext.getPackageName());
   mVoice.setImageResource(resId);
  }
 }

}

—-聲音播放工具類——

/**
 * @param
 * @author ldm
 * @description 播放聲音工具類
 * @time 2016/6/25 11:29
 */
public class MediaPlayerManager {
 //播放音頻API類：MediaPlayer
 private static MediaPlayer mMediaPlayer;
 //是否暫停
 private static boolean isPause;

 /**
  * @param
  * filePath：文件路徑
  * onCompletionListener：播放完成監聽
  * @description 播放聲音
  * @author ldm
  * @time 2016/6/25 11:30
  */
 public static void playSound(String filePath, MediaPlayer.OnCompletionListener onCompletionListener) {
  if (mMediaPlayer == null) {
   mMediaPlayer = new MediaPlayer();
   //設置一個error監聽器
   mMediaPlayer.setOnErrorListener(new MediaPlayer.OnErrorListener() {

    public boolean onError(MediaPlayer arg0, int arg1, int arg2) {
     mMediaPlayer.reset();
     return false;
    }
   });
  } else {
   mMediaPlayer.reset();
  }

  try {
   mMediaPlayer.setAudioStreamType(android.media.AudioManager.STREAM_MUSIC);
   mMediaPlayer.setOnCompletionListener(onCompletionListener);
   mMediaPlayer.setDataSource(filePath);
   mMediaPlayer.prepare();
   mMediaPlayer.start();
  } catch (Exception e) {

  }
 }

 /**
  * @param
  * @description 暫停播放
  * @author ldm
  * @time 2016/6/25 11:31
  */
 public static void pause() {
  if (mMediaPlayer != null && mMediaPlayer.isPlaying()) { //正在播放的時候
   mMediaPlayer.pause();
   isPause = true;
  }
 }

 /**
  * @param
  * @description 重新播放
  * @author ldm
  * @time 2016/6/25 11:31
  */
 public static void resume() {
  if (mMediaPlayer != null && isPause) {
   mMediaPlayer.start();
   isPause = false;
  }
 }

 /**
  * @param
  * @description 釋放操作
  * @author ldm
  * @time 2016/6/25 11:32
  */
 public static void release() {
  if (mMediaPlayer != null) {
   mMediaPlayer.release();
   mMediaPlayer = null;
  }
 }

—–錄音操作工具類—–

/**
 * @param
 * @author ldm
 * @description 錄音管理工具類
 * @time 2016/6/25 9:39
 */
public class AudioManager {
 //AudioRecord: 主要是實現邊錄邊播（AudioRecord+AudioTrack）以及對音頻的實時處理。
 // 優點：可以語音實時處理，可以實現各種音頻的封裝
 private MediaRecorder mMediaRecorder;
 //錄音文件
 private String mDir;
 //當前錄音文件目錄
 private String mCurrentFilePath;
 //單例模式
 private static AudioManager mInstance;
 //是否准備好
 private boolean isPrepare;

 //私有構造方法
 private AudioManager(String dir) {
  mDir = dir;
 }

 //對外公布獲取實例的方法
 public static AudioManager getInstance(String dir) {
  if (mInstance == null) {
   synchronized (AudioManager.class) {
    if (mInstance == null) {
     mInstance = new AudioManager(dir);
    }
   }
  }
  return mInstance;
 }

 /**
  * @param
  * @author ldm
  * @description 錄音准備工作完成回調接口
  * @time 2016/6/25 11:14
  */
 public interface AudioStateListener {
  void wellPrepared();
 }

 public AudioStateListener mAudioStateListener;

 /**
  * @param
  * @description 供外部類調用的設置回調方法
  * @author ldm
  * @time 2016/6/25 11:14
  */
 public void setOnAudioStateListener(AudioStateListener listener) {
  mAudioStateListener = listener;
 }

 /**
  * @param
  * @description 錄音准備工作
  * @author ldm
  * @time 2016/6/25 11:15
  */
 public void prepareAudio() {
  try {
   isPrepare = false;
   File dir = new File(mDir);
   if (!dir.exists()) {
    dir.mkdirs();//文件不存在，則創建文件
   }
   String fileName = generateFileName();
   File file = new File(dir, fileName);
   mCurrentFilePath = file.getAbsolutePath();
   mMediaRecorder = new MediaRecorder();
   // 設置輸出文件路徑
   mMediaRecorder.setOutputFile(file.getAbsolutePath());
   // 設置MediaRecorder的音頻源為麥克風
   mMediaRecorder.setAudioSource(MediaRecorder.AudioSource.MIC);
   // 設置音頻格式為RAW_AMR
   mMediaRecorder.setOutputFormat(MediaRecorder.OutputFormat.RAW_AMR);
   // 設置音頻編碼為AMR_NB
   mMediaRecorder.setAudioEncoder(MediaRecorder.AudioEncoder.AMR_NB);
   // 准備錄音
   mMediaRecorder.prepare();
   // 開始，必需在prepare()後調用
   mMediaRecorder.start();
   // 准備完成
   isPrepare = true;
   if (mAudioStateListener != null) {
    mAudioStateListener.wellPrepared();
   }
  } catch (Exception e) {
   e.printStackTrace();
  }
 }

 /**
  * @param
  * @description 隨機生成錄音文件名稱
  * @author ldm
  * @time 2016/6/25 、
  */
 private String generateFileName() {
  //隨機生成不同的UUID
  return UUID.randomUUID().toString() + ".amr";
 }

 /**
  * @param
  * @description 獲取音量值
  * @author ldm
  * @time 2016/6/25 9:49
  */
 public int getVoiceLevel(int maxlevel) {
  if (isPrepare) {
   try {
    // getMaxAmplitude返回的數值最大是32767
    return maxlevel * mMediaRecorder.getMaxAmplitude() / 32768 + 1;//返回結果1-7之間
   } catch (Exception e) {
    e.printStackTrace();
   }
  }
  return 1;
 }

 /**
  * @param
  * @description 釋放資源
  * @author ldm
  * @time 2016/6/25 9:50
  */
 public void release() {
  mMediaRecorder.stop();
  mMediaRecorder.reset();
  mMediaRecorder = null;
 }

 /**
  * @param
  * @description 錄音取消
  * @author ldm
  * @time 2016/6/25 9:51
  */
 public void cancel() {
  release();
  if (mCurrentFilePath != null) {
   //取消錄音後刪除對應文件
   File file = new File(mCurrentFilePath);
   file.delete();
   mCurrentFilePath = null;
  }

 }

 /**
  * @param
  * @description 獲取當前文件路徑
  * @author ldm
  * @time 2016/6/25 9:51
  */
 public String getCurrentFilePath() {

  return mCurrentFilePath;
 }
}

代碼中有注釋，就不貼圖了，和微信語音聊天界面一樣的，所以叫仿微信嘛，呵呵。運行了也可以看到效果。所有代碼可以從這裡下載：http://xiazai.jb51.net/201611/yuanma/AndroidWXchat(jb51.net).rar

以上就是本文的全部內容，希望對大家的學習有所幫助，也希望大家多多支持本站。
