Android Design新控件之TabLaout（二），仿微信實現App底部Tab布局

TabLayout的兩種常見設計布局：

接著接著舉例使用TabLayout+ViewPager來簡單實現一個類似於微信等App底部菜單欄布局，按照慣例，我們先來看看簡單的效果圖：

1、和上一篇文章一樣，我們需要在應用的build.gradle中添加support:design支持庫

compile 'com.android.support:design:23.1.1'

2、創建activity_main.xml文件，在布局文件中添加TabLayout和ViewPager

3、創建適配器FragmentAdapter.class

package com.per.tablayoutdome;

import android.support.v4.app.Fragment;
import android.support.v4.app.FragmentManager;
import android.support.v4.app.FragmentStatePagerAdapter;

import java.util.List;

/**
 * 適配器
 * Created by lijuan on 2016/8/23.
 */
public class FragmentAdapter extends FragmentStatePagerAdapter {
    public List list;
    private List titles;

    /**
     * 構造方法
     */
    public FragmentAdapter(FragmentManager fm, List list, List titles) {
        super(fm);
        this.list = list;
        this.titles = titles;
    }

    /**
     * 返回顯示的Fragment總數
     */
    @Override
    public int getCount() {
        return list.size();
    }

    /**
     * 返回要顯示的Fragment的某個實例
     */
    @Override
    public Fragment getItem(int position) {
        return list.get(position);
    }

    /**
     * 返回每個Tab的標題
     */
    @Override
    public CharSequence getPageTitle(int position) {
        return titles.get(position);
    }
}

4、選項卡頁面TabFragment.class

package com.per.tablayoutdome;

import android.os.Bundle;
import android.support.v4.app.Fragment;
import android.view.LayoutInflater;
import android.view.View;
import android.view.ViewGroup;
import android.widget.TextView;

/**
 * Created by lijuan on 2016/8/23.
 */
public class TabFragment extends Fragment {
    private TextView textView;

    public static TabFragment newInstance(int index){
        Bundle bundle = new Bundle();
        bundle.putInt("index", 'A' + index);
        TabFragment fragment = new TabFragment();
        fragment.setArguments(bundle);
        return fragment;
    }

    @Override
    public View onCreateView(LayoutInflater inflater, ViewGroup container, Bundle savedInstanceState) {
        View view = inflater.inflate(R.layout.tab_fragment, null);
        textView = (TextView) view.findViewById(R.id.text);
        textView.setText(String.valueOf((char) getArguments().getInt("index")));
        return view;
    }
}

5、選項卡布局文件tab_fragment.xml

6、主頁面中MainActivity.class

package com.per.tablayoutdome;

import android.os.Bundle;
import android.support.design.widget.TabLayout;
import android.support.v4.app.Fragment;
import android.support.v4.view.ViewPager;
import android.support.v7.app.AppCompatActivity;
import android.widget.ImageView;
import android.widget.TextView;

import java.util.ArrayList;
import java.util.List;
/**
 * 主頁面
 * Created by lijuan on 2016/8/23.
 */
public class MainActivity extends AppCompatActivity {
    private String[] titles = new String[]{"微信", "通訊錄", "發現", "我"};
    private TabLayout mTabLayout;
    private ViewPager mViewPager;
    private FragmentAdapter adapter;
    //ViewPage選項卡頁面集合
    private List mFragments;
    //Tab標題集合
    private List mTitles;
    /**
     * 圖片數組
     */
    private int[] mImgs=new int[]{R.drawable.selector_tab_weixin, R.drawable.selector_tab_friends, R.drawable.selector_tab_find,
            R.drawable.selector_tab_me};

    @Override
    protected void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);
        setContentView(R.layout.activity_main);

        mViewPager = (ViewPager) findViewById(R.id.viewpager);
        mTabLayout = (TabLayout) findViewById(R.id.tablayout);

        mTitles = new ArrayList<>();
        for (int i = 0; i < 4; i++) {
            mTitles.add(titles[i]);
        }

        mFragments = new ArrayList<>();
        for (int i = 0; i < mTitles.size(); i++) {
            mFragments.add(TabFragment.newInstance(i));
        }
        adapter = new FragmentAdapter(getSupportFragmentManager(), mFragments, mTitles);
        mViewPager.setAdapter(adapter);//給ViewPager設置適配器
        mTabLayout.setupWithViewPager(mViewPager);//將TabLayout和ViewPager關聯起來

        mTabLayout.setSelectedTabIndicatorHeight(0);
        for (int i = 0; i < mTitles.size(); i++) {
            //獲得到對應位置的Tab
            TabLayout.Tab itemTab = mTabLayout.getTabAt(i);
            if (itemTab != null) {
                //設置自定義的標題
                itemTab.setCustomView(R.layout.item_tab);
                TextView textView = (TextView) itemTab.getCustomView().findViewById(R.id.tv_name);
                textView.setText(mTitles.get(i));
                ImageView imageView= (ImageView) itemTab.getCustomView().findViewById(R.id.iv_img);
                imageView.setImageResource(mImgs[i]);
            }
        }
        mTabLayout.getTabAt(0).getCustomView().setSelected(true);
    }

}

其中需要注意幾點：
（1）mTabLayout.setSelectedTabIndicatorHeight(0);是為了不顯示tab底部的橫線；
（2）系統默認的TabLayout模式是MODE_FIXED，讓底部tab布局不可滑動；
（3）itemTab.setCustomView(R.layout.item_tab);用於設置自定義的標題

本片文章主要是的功能是TabLayout的Title使用自定義Layout，以上的代碼和上一篇文章差不多，下面我們根據需求自己添加Layout文件。

7、item_tab.xml

好了，本篇文章已經全部寫完了，存在總結不到位的地方還望指導，感謝^_^
