Android自定義加載控件實現數據加載動畫

本文實例為大家分享了Android自定義加載控件，第一次小人跑動的加載效果眼前一亮，相比傳統的PrograssBar高大上不止一點,於是走起，自定義了控件LoadingView去實現動態效果，可直接在xml中使用，具體實現如下

package com.*****.*****.widget;

import android.content.Context;
import android.graphics.drawable.AnimationDrawable;
import android.util.AttributeSet;
import android.view.LayoutInflater;
import android.view.View;
import android.widget.ImageView;
import android.widget.RelativeLayout;
import android.widget.TextView;




/**
 * Created by Xiaomu
 * 數據加載控件
 */
public class LoadingView extends RelativeLayout {
  private Context mContext;
  private ImageView loadingIv;
  private TextView loadingTv;

  public LoadingView(Context context) {
    super(context);
    this.mContext = context;
    initView();
  }

  public LoadingView(Context context, AttributeSet attrs) {
    super(context, attrs);
    this.mContext = context;
    initView();
  }

  private void initView() {
    View view = LayoutInflater.from(mContext).inflate(R.layout.loading, null);

    loadingIv = (ImageView) view.findViewById(R.id.loadingIv);
    loadingTv = (TextView) view.findViewById(R.id.loadingTv);

    AnimationDrawable animationDrawable = (AnimationDrawable) loadingIv.getBackground();
    if (animationDrawable != null)
      animationDrawable.start();

    addView(view);
  }

  public ImageView getLoadingIv() {
    return loadingIv;
  }

  public TextView getLoadingTv() {
    return loadingTv;
  }
}

2. xml布局文件

<?xml version="1.0" encoding="utf-8"?>
<RelativeLayout xmlns:android="http://schemas.android.com/apk/res/android"
  android:layout_width="match_parent"
  android:layout_height="wrap_content">

  <ImageView
    android:id="@+id/loadingIv"
    android:layout_width="@dimen/dimen_144_dip"
    android:layout_height="@dimen/dimen_162_dip"
    android:layout_centerHorizontal="true"
    android:background="@anim/loading_anim" />

  <TextView
    android:id="@+id/loadingTv"
    android:layout_width="match_parent"
    android:layout_height="wrap_content"
    android:layout_alignBottom="@+id/loadingIv"
    android:layout_centerHorizontal="true"
    android:gravity="center_horizontal"
    android:text="正在加載中..."
    android:textSize="15sp" />

</RelativeLayout>

3. loading_anim加載動畫的xml

<?xml version="1.0" encoding="utf-8"?>
<animation-list
  xmlns:android="http://schemas.android.com/apk/res/android"
  android:oneshot="false">
  <item
    android:drawable="@drawable/progress_loading_image_01"
    android:duration="150" />
  <item
    android:drawable="@drawable/progress_loading_image_02"
    android:duration="150" />
</animation-list>

以上就是本文的全部內容，希望對大家學習使用Android自定義加載控件有所啟發。
