借鑒http://blog.csdn.net/wangjinyu501/article/details/8169924而來

fragment是為了簡化actvity與view之間的交互而將activity對用戶交互的邏輯模塊化進行的封裝，它的好處是：1>簡化activity的邏輯控制 2>這些模塊化的fragment也更利於復用。

    Fragment有如下特點： 1>Fragment表現為一個activity用戶界面的一部分 2>一個activity可以有多個fragment 3>可以在多個activity中復用fragment 4>fragment有自己的生命周期 5>fragment有自己的事件處理 6>activity運行中，可以添加，移除一個fragment 7>fragment的生命周期有其宿主activity控制 如圖是效果圖 　　　　代碼運行雖然沒問題 但是我在viewpager中傳入動態數據時，數據在viewpager中顯示不對應或有的不顯示   看網上別人說是FragmentPagerAdapter中的instantiateItem方法要重寫，能力不夠 沒搞懂     如下是布局文件

<?xml version="1.0" encoding="utf-8"?>
<RelativeLayout xmlns:android="http://schemas.android.com/apk/res/android"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    android:background="#eee" >

    <LinearLayout
        android:id="@+id/ll_main_text"
        android:layout_width="match_parent"
        android:layout_height="50dp"
        android:background="#FF7200"
        android:gravity="center_vertical" >

        <LinearLayout
            android:layout_width="60dp"
            android:layout_height="match_parent"
            android:gravity="center" >

            <ImageView
                android:layout_width="30dp"
                android:layout_height="30dp"
                android:contentDescription="@null"
                android:scaleType="fitCenter"
                android:src="@drawable/arrow_left" />
        </LinearLayout>

        <View
            android:layout_width="0.5dp"
            android:layout_height="match_parent"
            android:background="#FE8B40" />

        <TextView
            android:layout_width="0dp"
            android:layout_height="match_parent"
            android:layout_weight="0.8"
            android:gravity="center"
            android:text="限時購"
            android:textColor="@android:color/white"
            android:textSize="20sp" />

        <View
            android:layout_width="0.5dp"
            android:layout_height="match_parent"
            android:background="#FE8B40" />

        <LinearLayout
            android:layout_width="60dp"
            android:layout_height="match_parent"
            android:gravity="center" >

            <ImageView
                android:layout_width="30dp"
                android:layout_height="30dp"
                android:contentDescription="@null"
                android:scaleType="fitCenter"
                android:src="@drawable/dropdown" />
        </LinearLayout>
    </LinearLayout>
    <!--  -->

    <LinearLayout
        android:id="@+id/ll_text_mainout"
        android:layout_width="match_parent"
        android:layout_height="55dp"
        android:layout_alignParentBottom="true"
        android:background="#eee"
        android:gravity="center_vertical"
        android:orientation="vertical" >

        <View
            android:layout_width="match_parent"
            android:layout_height="0.5dp"
            android:background="#999999" />

        <LinearLayout
            android:layout_width="match_parent"
            android:layout_height="match_parent"
            android:baselineAligned="false"
            android:gravity="center"
            android:orientation="horizontal" >

            <RelativeLayout
                android:layout_width="0dp"
                android:layout_height="match_parent"
                android:layout_weight="1" >

                <Button
                    android:id="@+id/bb_text_main1"
                    android:layout_width="match_parent"
                    android:layout_height="match_parent"
                    android:drawableTop="@drawable/main_topcolor"
                    android:paddingBottom="2dp"
                    android:paddingTop="5dp"
                    android:text="限時搶購"
                    android:textColor="@color/main_bottoncolor" />
            </RelativeLayout>

            <RelativeLayout
                android:layout_width="0dp"
                android:layout_height="match_parent"
                android:layout_weight="1" >

                <Button
                    android:layout_width="match_parent"
                    android:layout_height="match_parent"
                    android:drawableTop="@drawable/main_topcolor"
                    android:paddingBottom="2dp"
                    android:paddingTop="5dp"
                    android:text="限時搶購"
                    android:textColor="@color/main_bottoncolor" />
            </RelativeLayout>

            <RelativeLayout
                android:layout_width="0dp"
                android:layout_height="match_parent"
                android:layout_weight="1" >

                <Button
                    android:layout_width="match_parent"
                    android:layout_height="match_parent"
                    android:drawableTop="@drawable/main_topcolor"
                    android:paddingBottom="2dp"
                    android:paddingTop="5dp"
                    android:text="限時搶購"
                    android:textColor="@color/main_bottoncolor" />
            </RelativeLayout>
        </LinearLayout>
    </LinearLayout>
    <!--  -->

    <LinearLayout
        android:layout_width="match_parent"
        android:layout_height="match_parent"
        android:layout_above="@id/ll_text_mainout"
        android:layout_below="@id/ll_main_text"
        android:background="@android:color/white"
        android:orientation="vertical" >

        <LinearLayout
            android:id="@+id/linearlayout1"
            android:layout_width="match_parent"
            android:layout_height="50.0dip"
            android:layout_gravity="center"
            android:background="#FFFFFF" >

            <TextView
                android:id="@+id/text1"
                android:layout_width="0dp"
                android:layout_height="match_parent"
                android:layout_weight="1.0"
                android:gravity="center"
                android:text="頁卡1"
                android:textColor="#000000"
                android:textSize="22.0dip" />

            <TextView
                android:id="@+id/text2"
                android:layout_width="0dp"
                android:layout_height="match_parent"
                android:layout_weight="1.0"
                android:gravity="center"
                android:text="頁卡2"
                android:textColor="#000000"
                android:textSize="22.0dip" />

            <TextView
                android:id="@+id/text3"
                android:layout_width="0dp"
                android:layout_height="match_parent"
                android:layout_weight="1.0"
                android:gravity="center"
                android:text="頁卡3"
                android:textColor="#000000"
                android:textSize="22.0dip" />
        </LinearLayout>

        <TextView
            android:id="@+id/cursor"
            android:layout_width="100dp"
            android:layout_height="5dp"
            android:background="#990033" />

        <android.support.v4.view.ViewPager
            android:id="@+id/vPager"
            android:layout_width="wrap_content"
            android:layout_height="wrap_content"
            android:layout_gravity="center"
            android:background="#000000"
            android:flipInterval="30"
            android:persistentDrawingCache="animation" />
    </LinearLayout>

</RelativeLayout>

主代碼
如下

package org.xml.demo.viewpager;

import java.util.ArrayList;

import ogg.huanxin.huadong.R;
import android.os.Bundle;
import android.support.v4.app.Fragment;
import android.support.v4.app.FragmentActivity;
import android.support.v4.app.FragmentManager;
import android.support.v4.app.FragmentPagerAdapter;
import android.support.v4.view.ViewPager;
import android.support.v4.view.ViewPager.OnPageChangeListener;
import android.util.DisplayMetrics;
import android.view.Display;
import android.view.View;
import android.view.Window;
import android.widget.LinearLayout;
import android.widget.LinearLayout.LayoutParams;
import android.widget.TextView;

public class MyViewpager extends FragmentActivity {
    private ViewPager mPager;
    private TextView barText;
    private TextView view1, view2, view3;
    private ArrayList<Fragment> fragmentlist;
    private int currIndex;// 當前的葉卡標號

    @Override
    protected void onCreate(Bundle arg0) {
        // TODO Auto-generated method stub
        super.onCreate(arg0);
        requestWindowFeature(Window.FEATURE_NO_TITLE);
        // setContentView(R.layout.myciewpager);
        setContentView(R.layout.mypager);
        InitTextView();
        InitTextBar();
        InitViewPager();
    }

    /*
     * 初始化標簽名字
     */
    private void InitTextView() {
        // TODO Auto-generated method stub
        view1 = (TextView) findViewById(R.id.text1);
        view2 = (TextView) findViewById(R.id.text2);
        view3 = (TextView) findViewById(R.id.text3);

        view1.setOnClickListener(new txListener(0));
        view2.setOnClickListener(new txListener(1));
        view3.setOnClickListener(new txListener(2));

    }

    public class txListener implements View.OnClickListener {
        private int index = 0;

        public txListener(int i) {
            index = i;
        }

        @Override
        public void onClick(View arg0) {
            // TODO Auto-generated method stub
            mPager.setCurrentItem(index);
        }

    }

    /*
     * 初始化圖片的位移像素
     */
    private void InitTextBar() {
        // TODO Auto-generated method stub
        barText = (TextView) super.findViewById(R.id.cursor);
        Display display = getWindow().getWindowManager().getDefaultDisplay();
        // 得到顯示的屏寬度
        DisplayMetrics metrics = new DisplayMetrics();
        display.getMetrics(metrics);
        int tabLimeLength = metrics.widthPixels / 3;
        LayoutParams lp = (LayoutParams) barText.getLayoutParams();
        lp.width = tabLimeLength;
        barText.setLayoutParams(lp);
    }

    /*
     * 初始化ViewPager
     */
    private void InitViewPager() {
        // TODO Auto-generated method stub
        mPager = (ViewPager) findViewById(R.id.vPager);
        fragmentlist = new ArrayList<Fragment>();
        Fragment btFragment = new Fragment1();
        Fragment fragment2 = new Fragment2();
        Fragment fragment3 = new Fragment3();
        fragmentlist.add(btFragment);
        fragmentlist.add(fragment2);
        fragmentlist.add(fragment3);

        // 給ViewPager設置適配器
        mPager.setAdapter(new MyFragmentPagerAdapter(
                getSupportFragmentManager(), fragmentlist));
        mPager.setCurrentItem(0); // 設置當前顯示標簽頁為第一頁
        // mPager.setOnPageChangeListener(new MyPn);
        mPager.setOnPageChangeListener(new MyOnpageChangeListener());// 頁面變化時的監聽器
    }

    private class MyOnpageChangeListener implements OnPageChangeListener {

        @Override
        public void onPageScrollStateChanged(int arg0) {
            // onPageScrollStateChanged(int arg0)
            // 表示當前滑動的狀態，只有三個狀態0（END）,1(PRESS) , 2(UP)，

        }

        @Override
        public void onPageScrolled(int arg0, float arg1, int arg2) {
            // onPageScrolled(int arg0, float arg1, int arg2)
            // arg0表示目標，arg1表示偏移的百分比，arg2表示偏移的像素
            LinearLayout.LayoutParams ll = (LayoutParams) barText
                    .getLayoutParams();
            if (currIndex == arg0) {
                ll.leftMargin = (int) (currIndex * barText.getWidth() + arg1
                        * barText.getWidth());
            } else if (currIndex > arg0) {
                ll.leftMargin = (int) (currIndex * barText.getWidth() - (1 - arg1)
                        * barText.getWidth());
            }
            barText.setLayoutParams(ll);
        }

        @Override
        public void onPageSelected(int arg0) {
            // onPageSelected(int arg0) 指的是當前選擇的是哪個頁面
            currIndex = arg0;
            // int i = currIndex + 1;
            // Toast.makeText(MyViewpager.this, "您選擇了第" + i + "個葉卡",
            // Toast.LENGTH_SHORT).show();
        }

    }

    private class MyFragmentPagerAdapter extends FragmentPagerAdapter {
        private ArrayList<Fragment> list;

        public MyFragmentPagerAdapter(FragmentManager fm,
                ArrayList<Fragment> list) {
            super(fm);
            this.list = list;
            // TODO Auto-generated constructor stub
        }

        @Override
        public Fragment getItem(int arg0) {
            // TODO Auto-generated method stub
            return list.get(arg0);
        }

        @Override
        public int getCount() {
            // TODO Auto-generated method stub
            return list.size();
        }

        @Override
        public int getItemPosition(Object object) {
            // TODO Auto-generated method stub
            return super.getItemPosition(object);
        }

    }
}

其中的fragment的一個主代碼和布局如下

其中3個fragment你可以隨便寫的

package org.xml.demo.viewpager; import org.xml.demo.MyGridView; import org.xml.demo.ProducteGridAdapter; import ogg.huanxin.huadong.R; import android.os.Bundle; import android.support.v4.app.Fragment; import android.view.LayoutInflater; import android.view.View; import android.view.ViewGroup; import android.widget.AdapterView; import android.widget.AdapterView.OnItemClickListener; import android.widget.Toast; public class Fragment1 extends Fragment { private MyGridView myGridView; /** 產品的適配器 */ private ProducteGridAdapter producteGridAdapter; @Override public View onCreateView(LayoutInflater inflater, ViewGroup container, Bundle savedInstanceState) { return inflater.inflate(R.layout.fragment1, container, false); } @Override public void onActivityCreated(Bundle savedInstanceState) { super.onActivityCreated(savedInstanceState); setFindViewById(); setListener(); } private void setFindViewById() { myGridView = (MyGridView) getActivity().findViewById( R.id.my_fragment1_view); producteGridAdapter = new ProducteGridAdapter(getActivity()); myGridView.setAdapter(producteGridAdapter); } private void setListener() { myGridView.setOnItemClickListener(new OnItemClickListener() { @Override public void onItemClick(AdapterView<?> arg0, View arg1, int arg2, long arg3) { // TODO Auto-generated method stub Toast.makeText(getActivity(), "你點擊了" + arg2, Toast.LENGTH_SHORT) .show(); } }); } } View Code <?xml version="1.0" encoding="utf-8"?> <LinearLayout xmlns:android="http://schemas.android.com/apk/res/android" android:layout_width="match_parent" android:layout_height="match_parent" android:orientation="vertical" > <ImageView android:layout_width="match_parent" android:layout_height="100dp" android:contentDescription="@null" android:visibility="gone" android:scaleType="fitCenter" android:src="@drawable/a" /> <ScrollView android:layout_width="match_parent" android:layout_height="wrap_content" > <LinearLayout android:layout_width="match_parent" android:layout_height="wrap_content" android:orientation="vertical" > <org.xml.demo.MyGridView android:id="@+id/my_fragment1_view" android:layout_width="match_parent" android:layout_height="wrap_content" android:horizontalSpacing="4dp" android:numColumns="2" android:verticalSpacing="7dp" > </org.xml.demo.MyGridView> </LinearLayout> </ScrollView> </LinearLayout> View Code
