Android開發入門（十四）顯示圖像 14.3 GridView

GridView是一個可滑動的二維平面視圖。通常，用GridView去顯示一些圖片。下面展示如何使用GridView 。

1. 創建一個工程，Grid。

2. 在res/drawable-mdpi下面放一些圖片。

3. main.xml 中的代碼。

<?xml version="1.0" encoding="utf-8"?>
<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
    android:layout_width="fill_parent"
    android:layout_height="fill_parent"
    android:orientation="vertical" >

<GridView
    android:id="@+id/gridview"
    android:layout_width="fill_parent"
    android:layout_height="fill_parent"
    android:numColumns="auto_fit"
    android:verticalSpacing="10dp"
    android:horizontalSpacing="10dp"
    android:columnWidth="90dp"
    android:stretchMode="columnWidth"
    android:gravity="center" />

</LinearLayout>

4. GridActivity.java中的代碼。

public class GridActivity

extends Activity {
    //---the images to display---
    Integer[] imageIDs = {
            R.drawable.pic1,
            R.drawable.pic2,
            R.drawable.pic3,
            R.drawable.pic4,
            R.drawable.pic5,
            R.drawable.pic6,
            R.drawable.pic7
    };

    /** Called when the activity is first created. */
    @Override
    public void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);
        setContentView(R.layout.main);

        GridView gridView = (GridView) findViewById(R.id.gridview);
        gridView.setAdapter(new ImageAdapter(this));

        gridView.setOnItemClickListener(new OnItemClickListener()
        {
            public void onItemClick(AdapterView<?> parent,
            View v, int position, long id)
            {
                Toast.makeText(getBaseContext(),
                        "pic" + (position + 1) + " selected",
                        Toast.LENGTH_SHORT).show();
            }
        });

    }

    public class ImageAdapter extends BaseAdapter
    {
        private Context context;

        public ImageAdapter(Context c)
        {
            context = c;
        }

        //---returns the number of images---
        public int getCount() {
            return imageIDs.length;
        }

        //---returns the item---
        public Object getItem(int position) {
            return position;
        }

        //---returns the ID of an item---
        public long getItemId(int position) {
            return position;
        }

        //---returns an ImageView view---
        public View getView(int position, View convertView,
        ViewGroup parent)
        {
            ImageView imageView;
            if (convertView == null) {
                imageView = new ImageView(context);
                imageView.setLayoutParams(new
                    GridView.LayoutParams(85, 85));
                imageView.setScaleType(
                    ImageView.ScaleType.CENTER_CROP);
                imageView.setPadding(5, 5, 5, 5);
            } else {
                imageView = (ImageView) convertView;
            }
            imageView.setImageResource(imageIDs[position]);
            return imageView;
        }
    }

}
