Android App中實現簡單的刮刮卡抽獎效果的實例詳解

主要思想：
將一個view設計成多層：背景層，含中獎信息等；
遮蓋層，用於刮獎，使用關聯一個Bitmap的Canvas
在該Bitmap上，使用它的canvas.drawPath的api來處理 手勢滑動(類似刮獎的動作)
使用paint.setXfermode 來進行消除手勢滑動區域

public class GuaView extends View {

  private Bitmap mBitmap; //遮蓋的圖層
  private Canvas mCanvas; //繪制遮蓋圖層
  private Paint mOuterPaint;
  private Path mPath;
  private float mLastX;
  private float mLastY;

  private Bitmap mCoverBitmap; //遮蓋圖
  private int mWidth, mHeight;
  private Paint mInnerPaint;
  private String mInfo;


  public GuaView(Context context) {
    this(context, null);
  }

  public GuaView(Context context, AttributeSet attrs) {
    super(context, attrs);

    init();
  }

  private void init() {
    mPath = new Path();
    mOuterPaint = new Paint();
    mInnerPaint = new Paint();
    mCoverBitmap = BitmapFactory.decodeResource(getResources(), R.drawable.fg_guaguaka);

    mInfo = "￥ 5 0 0";
  }

  @Override
  protected void onMeasure(int widthMeasureSpec, int heightMeasureSpec) {
    super.onMeasure(widthMeasureSpec, heightMeasureSpec);
    mWidth = mCoverBitmap.getWidth();
    mHeight = mCoverBitmap.getHeight();
    setMeasuredDimension(mWidth, mHeight);

    mBitmap = Bitmap.createBitmap(mWidth, mHeight, Bitmap.Config.ARGB_8888);
    mCanvas = new Canvas(mBitmap);
    mCanvas.drawBitmap(mCoverBitmap, 0, 0, null);

    setOuterPaint();
    setInnerPaint();

  }

  private void setInnerPaint() {
    mInnerPaint.setColor(Color.RED);
    mInnerPaint.setStyle(Paint.Style.STROKE);
    mInnerPaint.setStrokeCap(Paint.Cap.ROUND);
    mInnerPaint.setStrokeJoin(Paint.Join.ROUND);
    mInnerPaint.setAntiAlias(true);
    mInnerPaint.setDither(true); //防抖
    mInnerPaint.setStrokeWidth(5);
    mInnerPaint.setTextSize(100);
    mInnerPaint.setTextAlign(Paint.Align.CENTER);
  }

  private void setOuterPaint() {
    mOuterPaint.setColor(Color.GREEN);
    mOuterPaint.setStyle(Paint.Style.STROKE);
    mOuterPaint.setStrokeCap(Paint.Cap.ROUND);
    mOuterPaint.setStrokeJoin(Paint.Join.ROUND);
    mOuterPaint.setAntiAlias(true);
    mOuterPaint.setDither(true); //防抖
    mOuterPaint.setStrokeWidth(20);
  }

  @Override //Path
  public boolean onTouchEvent(MotionEvent event) {
    float x = event.getX();
    float y = event.getY();
    switch (event.getAction()) {
      case MotionEvent.ACTION_DOWN:
        mLastX = x;
        mLastY = y;
        mPath.moveTo(x, y);
        break;
      case MotionEvent.ACTION_MOVE:
        float deltaX = Math.abs(x - mLastX);
        float deltaY = Math.abs(y - mLastY);
        if (deltaX > 5 || deltaY > 5) {
          mPath.lineTo(x, y);
        }
        mLastX = x;
        mLastY = y;
        break;
      case MotionEvent.ACTION_UP:
        break;
    }
    invalidate();//調用onDraw
    return true;
  }

  @Override
  protected void onDraw(Canvas canvas) {
    super.onDraw(canvas);

    canvas.drawColor(Color.parseColor("#bbbbbb")); //背景底色 灰色
    canvas.drawText(mInfo, mWidth / 2, mHeight / 4 * 3, mInnerPaint); //繪制文本
    canvas.drawBitmap(mBitmap, 0, 0, null); //繪制mBitmap  這是一個可變的bitmap，通過mCanvas繪制，首先繪制了mCoverBitmap
    drawPath();

  }

  private void drawPath() {
    //使用該mode：dst和src相交後， 只保留dst，且除去相交的部份
    mOuterPaint.setXfermode(new PorterDuffXfermode(PorterDuff.Mode.DST_OUT));
    mCanvas.drawPath(mPath, mOuterPaint);
  }
}

Paint.Join 連續畫筆銜接時：

•         MITER 在外邊緣以一個銳角連接
•         ROUND 以圓弧
•         BEVEL 以直線

Paint.Cap 指定對於 線和路徑(lines and paths) 的開始和結束點的處理方式：

•         BUTT  ends with the path  不超越它
•         ROUND  with the center at the end of the path 半圓
•         SQUARE  with the center at the end of the path 方形
