android NFC開發案例+MifareClassic格式密碼修改（鍵值keyA修改）

在開始之前可以先了解一些NFC的的基礎知識。
感謝Eternal_memory 和 SkySeraph
部分解析
BaseMethodWebActivity是Activity的子類
showToastMessage是單純的Toast通知
DataValues.NFCWriteLength 是長度限制

下面是我的開發代碼，希望對你有幫助。

package com.Base;

import java.io.ByteArrayOutputStream;
import java.io.IOException;
import java.io.UnsupportedEncodingException;
import java.nio.charset.Charset;
import java.text.DateFormat;
import java.text.SimpleDateFormat;
import java.util.Date;
import java.util.List;
import java.util.Locale;
import com.main.HZZH.MenuActivity;
import cn.data.bean.DataValues;
import cn.data.bean.PublicMethod;
import android.app.Activity;
import android.app.AlertDialog;
import android.app.PendingIntent;
import android.content.Context;
import android.content.DialogInterface;
import android.content.Intent;
import android.nfc.FormatException;
import android.nfc.NdefMessage;
import android.nfc.NdefRecord;
import android.nfc.NfcAdapter;
import android.nfc.Tag;
import android.nfc.tech.MifareClassic;
import android.nfc.tech.MifareUltralight;
import android.nfc.tech.Ndef;
import android.os.Bundle;
import android.os.Parcelable;
import android.provider.Settings;
import android.text.Selection;
import android.text.Spannable;
import android.util.Log;
import android.view.KeyEvent;
import android.view.View;
import android.view.inputmethod.InputMethodManager;
import android.widget.Button;
import android.widget.EditText;
import android.widget.TextView;
import android.widget.Toast;

public class NFCActivity extends BaseMethodWebActivity {
    private static final DateFormat TIME_FORMAT = SimpleDateFormat
            .getDateTimeInstance();
    private NfcAdapter mAdapter;
    private PendingIntent mPendingIntent;
    private NdefMessage mNdefPushMessage;
    private Tag intenTag;
    private String NdefRecordTypeByte01 = "http://";
    private String NdefRecordTypeByte02 = "www.baidu.com";
    private String NdefRecordTypeByte03 = "?";
    private int NFCDataType = 0;
    private final int MifareClassicType = 1,MifareUltralightType = 2,OtherType = 3;
    //扇位置
    private short sectorAddress = 6;
    //修改密碼
    private byte[] myKeyA = {'h','9','^','a','-','8'};
    private int NFCBarCodeLength = 16*3;
    public EditText NFCEditText = null;

    @Override
    protected void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);
        resolveIntent(getIntent());
        // 獲取默認的NFC控制器
        mAdapter = NfcAdapter.getDefaultAdapter(this);
        //攔截系統級的NFC掃描，例如掃描藍牙
        mPendingIntent = PendingIntent.getActivity(this, 0, new Intent(this,
                getClass()).addFlags(Intent.FLAG_ACTIVITY_SINGLE_TOP), 0);
        mNdefPushMessage = new NdefMessage(new NdefRecord[] { newTextRecord("",
                Locale.ENGLISH, true) });
    }

    @Override
    protected void onResume() {
        super.onResume();
        if (mAdapter != null) {
            //隱式啟動
            mAdapter.enableForegroundDispatch(this, mPendingIntent, null, null);
            mAdapter.enableForegroundNdefPush(this, mNdefPushMessage);
        }
    }

    @Override
    protected void onPause() {
        super.onPause();
        if (mAdapter != null) {
            //隱式啟動
            mAdapter.disableForegroundDispatch(this);
            mAdapter.disableForegroundNdefPush(this);
        }
    }

    //  //16進制字符串轉換為String
    //  private String hexString = "0123456789ABCDEF";
    //  public String decode(String bytes) {
    //      if (bytes.length() != 30) {
    //          return null;
    //      }
    //      ByteArrayOutputStream baos = new ByteArrayOutputStream(
    //              bytes.length() / 2);
    //      // 將每2位16進制整數組裝成一個字節
    //      for (int i = 0; i < bytes.length(); i += 2)
    //          baos.write((hexString.indexOf(bytes.charAt(i)) << 4 | hexString
    //                  .indexOf(bytes.charAt(i + 1))));
    //      return new String(baos.toByteArray());
    //  }
    //   //字符序列轉換為16進制字符串
    //    private String bytesToHexString(byte[] src) {
    //        StringBuilder stringBuilder = new StringBuilder("0x");
    //        if (src == null || src.length <= 0) {
    //            return null;
    //        }
    //        char[] buffer = new char[2];
    //        for (int i = 0; i < src.length; i++) {
    //            buffer[0] = Character.forDigit((src[i] >>> 4) & 0x0F, 16);
    //            buffer[1] = Character.forDigit(src[i] & 0x0F, 16);
    //            System.out.println(buffer);
    //            stringBuilder.append(buffer);
    //        }
    //        return stringBuilder.toString();
    //    }

    //  // 字符序列轉換為16進制字符串
    //  private String bytesToHexString(byte[] src, boolean isPrefix) {
    //      StringBuilder stringBuilder = new StringBuilder();
    //      if (isPrefix == true) {
    //          stringBuilder.append("0x");
    //      }
    //      if (src == null || src.length <= 0) {
    //          return null;
    //      }
    //      char[] buffer = new char[2];
    //      for (int i = 0; i < src.length; i++) {
    //          buffer[0] = Character.toUpperCase(Character.forDigit(
    //                  (src[i] >>> 4) & 0x0F, 16));
    //          buffer[1] = Character.toUpperCase(Character.forDigit(src[i] & 0x0F,
    //                  16));
    //          System.out.println(buffer);
    //          stringBuilder.append(buffer);
    //      }
    //      return stringBuilder.toString();
    //  }

    /**
     * 驗證扇sector的密碼.
     * @param mfc
     * @param sector
     * @return
     */
    private Boolean isKeyMifareClassicEnable(MifareClassic mfc,int sectorIndex){
        boolean auth = false;
        try {
            auth = mfc.authenticateSectorWithKeyA(sectorIndex,
                    MifareClassic.KEY_DEFAULT);
            if(!auth){
                auth = mfc.authenticateSectorWithKeyA(sectorIndex,
                        myKeyA);
            }
            if(!auth){
                auth = mfc.authenticateSectorWithKeyA(sectorIndex,
                        MifareClassic.KEY_NFC_FORUM);
            }
        } catch (IOException e) {
            Log.e(TAG, "IOException while authenticateSectorWithKey MifareClassic...", e);
        }
        return auth;
    }

    /**
     * 將數據寫入扇，扇中每塊必須16位
     * @param mfc
     * @param barCodeByte
     * @param sectorIndex
     * @return
     */
    private Boolean writeMifareClassicBarCode(MifareClassic mfc,byte[] barCodeByte,int sectorIndex){
        Boolean flag = false;
        int bCount = mfc.getBlockCountInSector(sectorIndex);
        //獲取block起始編號
        int bIndex = mfc.sectorToBlock(sectorIndex);
        int barIndexCount  = barCodeByte.length/16 +1;
        for(int i=0;i= 0){
                for(int j = 0;j < 16;j++){
                    if(j+i*16 < barCodeByte.length){
                        bar[j] = barCodeByte[j+i*16];
                    }else{
                        bar[j] = 0;
                    }
                }
            }
            try {
                mfc.writeBlock(bIndex, bar);
                bIndex++;
                if(i == bIndex - 2){
                    flag = true;
                }
            } catch (IOException e) {
                Log.e(TAG, "IOException while writeMifareClassicBarCode MifareClassic...", e);
            }
        }
        return flag;
    }

    /**
     * 寫入數據的方法
     * @param barCode
     * @param otherStr
     */
    protected void WriteMothed(String barCode,String otherStr){
        byte[] data = null;
        if(otherStr !=null){
            data = otherStr.getBytes(Charset.forName("UTF-8"));
        }
        if(barCode == null || barCode.length() < 4 || barCode.getBytes().length > NFCBarCodeLength){
            showToastMessage("要寫入的數據不正確！");
            return ;
        }
        if(data.length > DataValues.NFCWriteLength){
            showToastMessage("非條碼數據不超過"+DataValues.NFCWriteLength+"！");
            return ;
        }
        if (intenTag != null) {
            switch (NFCDataType) {
            case MifareClassicType:
                //MifareClassicl類型寫入
                MifareClassic mfc = MifareClassic.get(intenTag);
                int otherStrIndex = 0;
                try {
                    int bAllCount = 0;
                    if(barCode != null){
                        bAllCount = 1;
                    }
                    if(data != null){
                        bAllCount += data.length/16 + 1;
                    }

                    for(int j = sectorAddress;j < 16 && j < bAllCount+sectorAddress;j++){
                        //在刪去1 塊4、5 寫入數據
                        mfc.connect();
                        boolean auth = false;
                        byte[] KeyValue = null;
                        if (isKeyMifareClassicEnable(mfc,j)) {
                            KeyValue = mfc.readBlock(4*j+3);
                        }
                        mfc.close();
                        mfc.connect();
                        if (isKeyMifareClassicEnable(mfc,j) && KeyValue != null) {
                            if(j == sectorAddress){
                                writeMifareClassicBarCode(mfc,barCode.getBytes(Charset.forName("UTF-8")),j);
                            }else{
                                int count = 16*3;
                                byte[] strByte = new byte[count];
                                for(int z = 0;z < count;z++){
                                    if(otherStrIndex < data.length){
                                        strByte[z] = data[otherStrIndex];
                                        otherStrIndex++;
                                    }else{
                                        break;
                                    }
                                }
                                writeMifareClassicBarCode(mfc, strByte, j);
                            }
                            //修改鍵值，keyA存放在每扇最後一塊
                            for(int i = 0;i<6;i++){
                                KeyValue[i] = myKeyA[i];
                            }
                            mfc.writeBlock(4*j+3, KeyValue);
                            showToastMessage("寫入數據成功！");
                            mfc.close();
                        }else{
                            showToastMessage("塊密碼不正確！");
                        }
                    }
                } catch (Exception e) {
                    showToastMessage("寫入數據失敗！");
                    Log.e(TAG, "IOException while write MifareClassic...", e);
                } finally {
                    try {
                        mfc.close();
                    } catch (IOException e) {
                        Log.e(TAG, "IOException while closing MifareClassic...", e);
                    }
                }
                break;
            case MifareUltralightType:
                MifareUltralight ultralight = MifareUltralight.get(intenTag);
                try {
                    ultralight.connect();
                    //每頁4個字符2個漢字，共16頁
                    ultralight.writePage(4, "abcd".getBytes(Charset.forName("US-ASCII")));
                    ultralight.writePage(5, "efgh".getBytes(Charset.forName("US-ASCII")));
                    ultralight.writePage(6, "ijkl".getBytes(Charset.forName("US-ASCII")));
                    ultralight.writePage(7, "mnop".getBytes(Charset.forName("US-ASCII")));
                    showToastMessage("寫入數據成功！");
                } catch (Exception e) {
                    showToastMessage("寫入數據失敗！");
                    Log.e(TAG, "IOException while write MifareUltralight...", e);
                } finally {
                    try {
                        ultralight.close();
                    } catch (IOException e) {
                        Log.e(TAG, "IOException while closing MifareUltralight...", e);
                    }
                }
                break;
            case OtherType:
                //新建NdefRecord數組，本例中數組只有一個元素
                NdefRecord re = null;
                try{
                    re = createRecord(otherStr+barCode);
                }catch (Exception e) {
                    showToastMessage("新建NdefRecord數組失敗！");
                    Log.e(TAG, "IOException while create other NdefRecord...", e);
                    return;
                }
                NdefRecord[] records = {re};
                //新建一個NdefMessage實例
                NdefMessage message = new NdefMessage(records);
                // 解析TAG獲取到NDEF實例
                Ndef ndef = Ndef.get(intenTag);
                if(ndef != null ){
                    // 打開連接
                    try {
                        ndef.connect();
                        ndef.writeNdefMessage(message);
                        showToastMessage("寫入數據成功！");
                    } catch (Exception e) {
                        showToastMessage("寫入數據失敗！");
                        Log.e(TAG, "IOException while write other...", e);
                    } finally{
                        try {
                            ndef.close();
                        } catch (Exception e) {
                            Log.e(TAG, "IOException while closing other...", e);
                        }
                    }
                }
                break;
            }
        } else {
            showToastMessage("設備與nfc卡連接斷開，請重新連接...");
        }
    }

    /**
     * 創建NdefRecord實例
     * @param str
     * @return
     * @throws UnsupportedEncodingException
     */
    protected NdefRecord createRecord( String str ) throws UnsupportedEncodingException {
        NdefRecord textRecord = NdefRecord.createMime(NdefRecordTypeByte01+
                NdefRecordTypeByte02+
                NdefRecordTypeByte03,
                str.getBytes(Charset.forName("US-ASCII")));
        //      //組裝字符串，准備好你要寫入的信息
        //      String msg = str;
        //      //將字符串轉換成字節數組
        //      byte[] textBytes = msg.getBytes();
        //      //將字節數組封裝到一個NdefRecord實例中去
        //      NdefRecord textRecord = new NdefRecord(NdefRecord.TNF_MIME_MEDIA,
        //              NdefRecordTypeByte.getBytes(), new byte[] {}, textBytes);
        return textRecord;
    }

    private NdefRecord newTextRecord(String text, Locale locale,
            boolean encodeInUtf8) {
        byte[] langBytes = locale.getLanguage().getBytes(
                Charset.forName("UTF-8"));
        Charset utfEncoding = encodeInUtf8 ? Charset.forName("UTF-8") : Charset
                .forName("UTF-16");
        byte[] textBytes = text.getBytes(utfEncoding);
        int utfBit = encodeInUtf8 ? 0 : (1 << 7);
        char status = (char) (utfBit + langBytes.length);
        byte[] data = new byte[1 + langBytes.length + textBytes.length];
        data[0] = (byte) status;
        System.arraycopy(langBytes, 0, data, 1, langBytes.length);
        System.arraycopy(textBytes, 0, data, 1 + langBytes.length,
                textBytes.length);
        return new NdefRecord(NdefRecord.TNF_WELL_KNOWN, NdefRecord.RTD_TEXT,
                new byte[0], data);
    }

    //  private void showWirelessSettingsDialog() {
    //      AlertDialog.Builder builder = new AlertDialog.Builder(this);
    //      builder.setMessage("提示");
    //      builder.setPositiveButton(android.R.string.ok,
    //              new DialogInterface.OnClickListener() {
    //          public void onClick(DialogInterface dialogInterface, int i) {
    //              Intent intent = new Intent(
    //                      Settings.ACTION_WIRELESS_SETTINGS);
    //              startActivity(intent);
    //          }
    //      });
    //      builder.setNegativeButton(android.R.string.cancel,
    //              new DialogInterface.OnClickListener() {
    //          public void onClick(DialogInterface dialogInterface, int i) {
    //              finish();
    //          }
    //      });
    //      builder.create().show();
    //      return;
    //  }


    /**
     * 初步判斷是什麼類型NFC卡
     * @param intent
     */
    private void resolveIntent(Intent intent) {
        String action = intent.getAction();
        if (NfcAdapter.ACTION_TAG_DISCOVERED.equals(action)
                || NfcAdapter.ACTION_TECH_DISCOVERED.equals(action)
                || NfcAdapter.ACTION_NDEF_DISCOVERED.equals(action)) {
            Parcelable[] rawMsgs = intent
                    .getParcelableArrayExtra(NfcAdapter.EXTRA_NDEF_MESSAGES);
            NdefMessage[] msgs;
            intenTag = intent
                    .getParcelableExtra(NfcAdapter.EXTRA_TAG);
            if (rawMsgs != null) {
                msgs = new NdefMessage[rawMsgs.length];
                for (int i = 0; i < rawMsgs.length; i++) {
                    msgs[i] = (NdefMessage) rawMsgs[i];
                }
            } else {
                // Unknown tag type
                byte[] empty = new byte[0];
                byte[] id = intent.getByteArrayExtra(NfcAdapter.EXTRA_ID);
                byte[] payload = dumpTagData(intenTag).getBytes();
                NdefRecord record = new NdefRecord(NdefRecord.TNF_UNKNOWN,
                        empty, id, payload);
                NdefMessage msg = new NdefMessage(new NdefRecord[] { record });
                msgs = new NdefMessage[] { msg };
            }
            // Setup the views
            getNFCData(msgs);
        }
    }

    /**
     * 解析讀取的數據
     * @param p
     * @return
     */
    private String dumpTagData(Parcelable p) {
        StringBuilder sb = new StringBuilder();
        Tag tag = (Tag) p;
        //      String prefix = "android.nfc.tech.";
        //      sb.append("Technologies: ");
        //      for (String tech : tag.getTechList()) {
        //          sb.append(tech.substring(prefix.length()));
        //          sb.append(", ");
        //      }
        NFCDataType = 3;
        //      sb.delete(sb.length() - 2, sb.length());
        for (String tech : tag.getTechList()) {
            if (tech.equals(MifareClassic.class.getName())) {
                MifareClassic mifareTag = MifareClassic.get(tag);
                String type = "Unknown";
                switch (mifareTag.getType()) {
                case MifareClassic.TYPE_CLASSIC:
                    type = "Classic";
                    break;
                case MifareClassic.TYPE_PLUS:
                    type = "Plus";
                    break;
                case MifareClassic.TYPE_PRO:
                    type = "Pro";
                    break;
                }
                NFCDataType = 1;
                try {
                    //獲取 扇sectorAddress 塊barCdeBlock 的內容
                    mifareTag.connect();
                    int bCount;
                    int bIndex;
                    if (isKeyMifareClassicEnable(mifareTag,sectorAddress)) {
                        // 讀取扇區中的塊總數
                        bCount = mifareTag.getBlockCountInSector(sectorAddress);
                        //獲取扇區塊的起始編號
                        bIndex = mifareTag.sectorToBlock(sectorAddress);
                        for (int i = 0; i < bCount-1; i++) {
                            byte[] data = mifareTag.readBlock(bIndex);
                            sb.append(new String(data, Charset.forName("UTF-8")));
                            bIndex++;
                        }
                    } else {
                        showToastMessage("驗證失敗");
                    }
                } catch (Exception e) {
                    showToastMessage("讀取數據失敗！");
                    Log.e(TAG, "IOException while read MifareClassic...", e);
                }finally{
                    try {
                        mifareTag.close();
                    } catch (IOException e) {
                        Log.e(TAG, "IOException while closing MifareClassic...", e);
                    }
                }
            }

            if (tech.equals(MifareUltralight.class.getName())) {
                sb.append('\n');
                MifareUltralight mifareUlTag = MifareUltralight.get(tag);
                String type = "Unknown";
                switch (mifareUlTag.getType()) {
                case MifareUltralight.TYPE_ULTRALIGHT:
                    type = "Ultralight";
                    break;
                case MifareUltralight.TYPE_ULTRALIGHT_C:
                    type = "Ultralight C";
                    break;
                }
                NFCDataType = 2;
                sb.append("Mifare Ultralight type: ");
                sb.append(type);
            }
        }
        return sb.toString();
    }

    //  private String getHex(byte[] bytes) {
    //      StringBuilder sb = new StringBuilder();
    //      for (int i = bytes.length - 1; i >= 0; --i) {
    //          int b = bytes[i] & 0xff;
    //          if (b < 0x10)
    //              sb.append('0');
    //          sb.append(Integer.toHexString(b));
    //          if (i > 0) {
    //              sb.append(" ");
    //          }
    //      }
    //      return sb.toString();
    //  }
    //  private long getDec(byte[] bytes) {
    //      long result = 0;
    //      long factor = 1;
    //      for (int i = 0; i < bytes.length; ++i) {
    //          long value = bytes[i] & 0xffl;
    //          result += value * factor;
    //          factor *= 256l;
    //      }
    //      return result;
    //  }
    //  private long getReversed(byte[] bytes) {
    //      long result = 0;
    //      long factor = 1;
    //      for (int i = bytes.length - 1; i >= 0; --i) {
    //          long value = bytes[i] & 0xffl;
    //          result += value * factor;
    //          factor *= 256l;
    //      }
    //      return result;
    //  }

    /**
     * 取出NFC掃描的數據
     * @param msgs
     */
    private void getNFCData(NdefMessage[] msgs) {
        if (msgs == null || msgs.length == 0) {
            return;
        }
        //將字節數組轉換成字符串
        String str="";
        byte[] data = null;
        for(NdefMessage obj:msgs){
            NdefRecord record[] = obj.getRecords();
            for(NdefRecord recordObj:record){
                if(data == null){
                    data = recordObj.getPayload();
                }else{
                    byte[] oldData = data;
                    data = new byte[oldData.length + recordObj.getPayload().length];
                    for(int i = 0;i < oldData.length;i++){
                        data[i] = oldData[i];
                    }
                    for(int i = 0;i 3){
                NFCEditText.setText(str);
                CharSequence text = NFCEditText.getText();
                if (text instanceof Spannable) {
                    Spannable spanText = (Spannable)text;
                    Selection.setSelection(spanText, text.length());
                }
                if(NFCEditText.getText().toString().trim().length() > 3){
                    KeyEvent event = new KeyEvent(KeyEvent.ACTION_UP,KeyEvent.KEYCODE_ENTER);
                    NFCEditText.dispatchKeyEvent(event);
                }
            }
        }
    }

    @Override
    public boolean dispatchKeyEvent(KeyEvent event) {
        if(event.getKeyCode() == KeyEvent.KEYCODE_ENTER){
            /*隱藏軟鍵盤*/
            InputMethodManager inputMethodManager = (InputMethodManager) getSystemService(Context.INPUT_METHOD_SERVICE);
            if(inputMethodManager.isActive()){
                inputMethodManager.hideSoftInputFromWindow(this.getCurrentFocus().getWindowToken(), 0);
            }
            return true;
        }
        return super.dispatchKeyEvent(event);
    }

    //獲取系統隱式啟動的
    @Override
    public void onNewIntent(Intent intent) {
        setIntent(intent);
        resolveIntent(intent);
    }
}

其他如下：

1 AndroidMainifest.xml中添加權限

2、添加過濾器

3、添加支持的協議



      android.nfc.tech.IsoDep
        android.nfc.tech.NfcA
        android.nfc.tech.NfcB
        android.nfc.tech.NfcF
        android.nfc.tech.NfcV
        android.nfc.tech.Ndef
        android.nfc.tech.NdefFormatable
        android.nfc.tech.MifareClassic
        android.nfc.tech.MifareUltralight
